PIR Presence Sensor | Indoor Presence Sensor with Remote | Upto 8m Detection Range | ESY-P24

PIR Presence Detector ESY-P24, a high-precision motion sensor designed for responsive automation in indoor environments. With its wide 360° detection range and impressive 8-meter sensing distance, this ceiling-mounted sensor ensures consistent presence-based lighting control in offices, classrooms, lobbies, and other frequently used areas.

Tailored for maximum adaptability, the ESY-P24 features fully adjustable delay time, ambient light threshold, dimming levels, and a standby period—letting you fine-tune its performance for comfort, efficiency, and cost-saving outcomes. Its remote control support makes configuration effortless, even after installation. Compact, discreet, and effective, this PIR sensor is the ultimate solution for seamless lighting automation in modern smart-building setups.

Technical Specifications:

• Detection Angle: 360°
• Operating Volt: 110-270V/AC
• Power Frequency: 50-60Hz
• Load Capacity: Max 300 Watt
• Detection Distance: Max 8 MeterØ
• Delay Time: 10sec - 30 min (Adjustable)
• Ambient Light: 3- 2000 Lux (Adjustable)
• Installing Height: 2.2-6m
• Stand-by Period: 5min,10min, 15min, 30min, 60min, +∞ (choice)
• Stand-by Dimming Level: 10%, 20%, 30%, OFF(choice)
• Protection level: IP20
• Weight: 450 Grams
• Mounting Type: Surface Mount
• Technology Type: PIR with Remote
• Size: 20H x ø115D mm
• Marketed and Packed by : Esysense Tech Innovation Pvt Ltd
• Country of Origin : China
