Microwave Motion Sensor | 360° Ceiling-Mount | ESY -M30

Product Overview

The Esysense ESY-M30 Radar Motion Sensor Switch is an advanced recessed motion detection device designed for intelligent lighting automation in modern indoor spaces. Powered by 5.8GHz CW microwave radar technology, the sensor offers superior motion detection sensitivity compared to conventional PIR sensors, enabling it to detect even subtle movements within its coverage area. With a 360° detection angle and sensing range of up to 9 meters, the ESY-M30 provides reliable motion-based lighting control for corridors, offices, and residential interiors. It features adjustable delay time (10 seconds to 12 minutes) and ambient light sensitivity (3–2000 LUX), allowing users to configure when and how the connected lighting system operates. Designed for recessed ceiling installation, the sensor maintains a clean and minimal ceiling appearance while delivering efficient automation and energy savings in commercial and domestic environments.

Technical Specifications:

• Detection Angle : 360°
• Operating Volt : 110-270 V/AC
• Power Frequency : 50-60Hz
• HF System : 5.8 Ghz CW Radar ISM Band Rated
• Rated Load : Max 300W
• Weight: 450 Grams
• Detection Distance : 1-9m Diameter
• Delay Time : 10 sec - 12 min (Adjustable)
• Ambient Light : 3-2000 LUX (Adjustable)
• Installing Height : 2-4m
• Protection Level : IP20
• Mounting Type : Recessed Mount
• Marketed and Packed by : Esysense Tech Innovation pvt Ltd
• Country of Origin : China
