Motion Sensor Square Concealed Panel Light with Auto Dimmable | IP20 | 15W
Motion Sensor Square Concealed Panel Light with Auto Dimmable | IP20 | 15W
SKU:ESY-L15ED CW
Couldn't load pickup availability
Product Overview
The Esysense 15W Auto-Dimmable Motion Sensor Square LED Panel is a premium, high-efficiency lighting solution designed for sophisticated architectural interiors. Engineered for seamless, flush-fit concealment in false ceilings, this fixture merges minimalist design with advanced occupancy-sensing intelligence. Unlike basic motion-activated lights, this panel features auto-dimming technology, which fluidly modulates brightness based on real-time movement and ambient light levels, ensuring optimal comfort while significantly lowering energy overhead. Providing a soft, uniform, and flicker-free output, it is the perfect lighting upgrade for professional conference rooms, high-end retail environments, upscale offices, and modern residential living spaces.
Technical Specifications:
- Functionality : Auto Dimmable
- Detection Range : 9m
- Delay Time : 30sec
- IP Rating : IP20
- Detection Angle : 360°
- Input Voltage : 220-270V/AC
- Wattage : 15W
- Weight: 500 Grams
-
CCT Available : Warm White | Natural White | Cool White
- Packed & Marketed By: Esysense Innovation Pvt. Ltd.
- Manufactured By: IPREALM Technology Pvt. Ltd.
- Origin Country : India
Contact Support Team
+91 74283 89555 | +91 74283 81555
Register your Product
Register Warranty Terms of Serivce
ESYSENSE 4-Way Remote Control Switch
Control up to 4 lights, fans, or electrical appliances with a single wireless remote. The ESYSENSE 4-Way Remote Control Switch offers easy installation, reliable RF technology, and seamless operation for homes and commercial spaces.
Control 4 Devices with One Remote
Smart Wireless Switching for Everyday Convenience
Operate lights, ceiling fans, wall lamps, chandeliers, and other electrical appliances effortlessly with the ESYSENSE 4-Way Remote Control Switch. Powered by reliable RF technology, it offers seamless wireless control, easy installation, and a clutter-free smart living experience.
Key Highlights
- Controls up to 4 devices independently
- Reliable long-range RF wireless technology
- Compatible with lights, fans & appliances
- Quick retrofit installation
- No Wi-Fi or internet required
- deal for homes, offices & commercial spaces
How to Connect Your ESY-TC35 — Simple Wiring Guide
The ESY-TC35 is designed for quick, hassle-free installation inside your existing switchboard or junction box. Follow the diagram and the steps below to get your 4-channel remote control switch up and running in minutes.
Understanding the Terminals
Terminal What to Connect
- L (Line/Live) : Incoming 230V AC Live wire
- N (Neutral) : Incoming 230V AC Neutral wire
- OUT 1 – OUT 4 Load output for each channel (light/fan/device)
Step-by-Step Connection
Step 1 — Connect the Power Supply
Connect the Live (L) and Neutral (N) wires from your mains supply (110–240V AC) to the corresponding terminals on the receiver module. This powers the ESY-TC35.
Step 2 — Connect Your Loads
Connect each appliance (light, fan, or fixture) to its respective output terminal — OUT 1, OUT 2, OUT 3, OUT 4. Each channel independently controls one device, giving you full 4-way control from a single receiver.
Step 3 — Pair the Remote & Test
Power ON the circuit. Your remote and receiver come pre-paired out of the box. Press any button on the remote — your connected device should respond instantly within 8–15 metres range.
